Gas springs and folding mechanism
Gas springs assist opening and closing. The DAM version has an intermediate joint and opens to the left or right. The DAL version opens from both sides.
DOCK ANGEL · Loading dock protection
Foldable safety
barriers for
loading docks.
Side-folding safety barriers designed to help prevent people and forklifts from falling off loading docks between loading operations.
Safety tested by TÜV SÜD
Production monitored. Made in Germany.
DAM–3200 / Interactive product viewer Live 3D
Drag to rotate / Scroll to zoom↗
The interactive model is unavailable. This image shows the barrier in its closed position.
01 / Technology
Side-folding safety barrier
for industrial use.
DOCK ANGEL combines gas springs, a top rail, mid rail and 100 mm toe board in a robust steel construction. Its standardized design also allows use in other applications.
Top rail, mid rail and toe board
A 1,100 mm handrail height and 100 mm toe board. The toe board is double-angled for high stability and carefully finished edges.
Stainless steel pivots and igus® bearings
Stainless steel pivot points with maintenance-free, self-lubricating igus® plain bearings. Handles have a comfortable 27 mm diameter.
Product characteristics
- Steel profiles with 4 mm material thickness.
- Double-function locking mechanism; intermediate joint from an overall width of 2,000 mm.
- Padlock eyelets for locking the barrier in its closed position.
- Optional EUCHNER CET series safety switch with guard locking, on request.
- Identification plate with an individual serial number.
- Spare parts available for at least 10 years, including after later modifications we make to the product.
TÜV SÜD Product Service GmbH certification applies only to versions within the scope of our current certificate: production monitored, safety tested. The exceptions and extension in progress are explained in the notice above. View current TÜV coverage ↑
02 / Interactive product viewer
DAM-3200
in 3D.
Rotate the actual CAD model, view the opening sequence and compare surface finishes. Compatible phones can display the barrier in augmented reality.
DOCK ANGEL / DAM–3200
ClosedDrag to rotate · Pinch to zoom
The interactive model is unavailable. This image shows the barrier in its closed position.
Loading 3D model …
03 / The range
Loading dock safety barriers
DAS, DAM and DAL.
Three versions for overall widths from 1,200 to 6,400 mm. Compare the overall width, clear opening and height when open before choosing a model.
01 / DAS
One-piece barrier
DOCK ANGEL DAS
One-piece, side-folding barrier without an intermediate joint. Left-hand or right-hand opening.
Overall width1,200–2,000 mm
Compare dimensions ↗02 / DAM
Intermediate joint
DOCK ANGEL DAM
One-sided folding barrier with an intermediate joint. Left-hand or right-hand opening.
Overall width2,000–3,800 mm
Compare dimensions ↗03 / DAL
Two-sided opening
DOCK ANGEL DAL
Two-piece folding barrier with intermediate joints and opening from both sides.
Overall width4,000–6,400 mm
Compare dimensions ↗Construction & manufacturing
High-quality steel.
Made in Germany.
We at Euro Industry manufacture DOCK ANGEL in southwest Germany. Each barrier has a robust steel construction for industrial use, an identification plate and an individual serial number.
Contact Euro Industry ↗4mm
Steel profile material thickness
100mm
Double-angled toe board height
27mm
Handle diameter for comfortable operation
10years
Minimum spare-parts availability
04 / Specifications
Technical dimensions.
Compare overall width, usable opening and the height required when open. Every model has a 1,100 mm handrail height and 250 mm overall depth.
DOCK ANGEL DAS
One-piece, side-folding barrier without an intermediate joint. Left-hand or right-hand opening.
| Model | Overall width | Clear opening | Height when open | Purchase |
|---|---|---|---|---|
| DAS-1200 | 1,200 mm | 905 mm | 2,065 mm | Buy it here ↗ |
| DAS-1400 | 1,400 mm | 1,105 mm | 2,265 mm | Buy it here ↗ |
| DAS-1600 | 1,600 mm | 1,305 mm | 2,465 mm | Buy it here ↗ |
| DAS-1800 | 1,800 mm | 1,505 mm | 2,665 mm | Buy it here ↗ |
| DAS-2000 | 2,000 mm | 1,705 mm | 2,865 mm | Buy it here ↗ |
Dimensions in mm, supplied by us as the manufacturer. We confirm the availability of individual sizes; some listed technical sizes are supplied on request. The 3D viewer represents DAM-3200 only.
DOCK ANGEL DAM
One-sided folding barrier with an intermediate joint. Left-hand or right-hand opening.
| Model | Overall width | Clear opening | Height when open | Purchase |
|---|---|---|---|---|
| DAM-2000 | 2,000 mm | 1,500 mm | 1,950 mm | Buy it here ↗ |
| DAM-2100 | 2,100 mm | 1,600 mm | 2,000 mm | Buy it here ↗ |
| DAM-2200 | 2,200 mm | 1,700 mm | 2,050 mm | Buy it here ↗ |
| DAM-2400 | 2,400 mm | 1,900 mm | 2,150 mm | Buy it here ↗ |
| DAM-2500 | 2,500 mm | 2,000 mm | 2,200 mm | Buy it here ↗ |
| DAM-2600 | 2,600 mm | 2,100 mm | 2,250 mm | Buy it here ↗ |
| DAM-2800 | 2,800 mm | 2,300 mm | 2,350 mm | Buy it here ↗ |
| DAM-3000 | 3,000 mm | 2,500 mm | 2,450 mm | Buy it here ↗ |
| DAM-3200 | 3,200 mm | 2,700 mm | 2,550 mm | Buy it here ↗ |
| DAM-3400 | 3,400 mm | 2,900 mm | 2,650 mm | Buy it here ↗ |
| DAM-3600 | 3,600 mm | 3,100 mm | 2,750 mm | Buy it here ↗ |
| DAM-3800 | 3,800 mm | 3,300 mm | 2,850 mm | Buy it here ↗ |
Dimensions in mm, supplied by us as the manufacturer. We confirm the availability of individual sizes; some listed technical sizes are supplied on request. The 3D viewer represents DAM-3200 only.
DOCK ANGEL DAL
Two-piece folding barrier with intermediate joints and opening from both sides.
| Model | Overall width | Clear opening | Height when open | Purchase |
|---|---|---|---|---|
| DAL-4000 | 4,000 mm | 3,200 mm | 1,987 mm | Buy it here ↗ |
| DAL-4200 | 4,200 mm | 3,400 mm | 2,037 mm | Buy it here ↗ |
| DAL-4400 | 4,400 mm | 3,600 mm | 2,087 mm | Buy it here ↗ |
| DAL-4600 | 4,600 mm | 3,800 mm | 2,137 mm | Buy it here ↗ |
| DAL-4800 | 4,800 mm | 4,000 mm | 2,187 mm | Buy it here ↗ |
| DAL-5000 | 5,000 mm | 4,200 mm | 2,237 mm | Buy it here ↗ |
| DAL-5200 | 5,200 mm | 4,400 mm | 2,287 mm | Buy it here ↗ |
| DAL-5400 | 5,400 mm | 4,600 mm | 2,337 mm | Buy it here ↗ |
| DAL-5600 | 5,600 mm | 4,800 mm | 2,387 mm | Buy it here ↗ |
| DAL-5800 | 5,800 mm | 5,000 mm | 2,437 mm | Buy it here ↗ |
| DAL-6000 | 6,000 mm | 5,200 mm | 2,487 mm | Buy it here ↗ |
| DAL-6200 | 6,200 mm | 5,400 mm | 2,537 mm | Buy it here ↗ |
| DAL-6400 | 6,400 mm | 5,600 mm | 2,587 mm | Buy it here ↗ |
Dimensions in mm, supplied by us as the manufacturer. We confirm the availability of individual sizes; some listed technical sizes are supplied on request. The 3D viewer represents DAM-3200 only.
05 / In context
DOCK ANGEL
at the loading dock.
Good to know
A few practical
questions.
How do I choose the correct size?
Start with the clear opening you need, then check the overall width, 250 mm depth and required open height in the tables. The model designation refers to overall width, not clear opening. Confirm mounting conditions and suitability with Euro Industry before ordering.
Can I choose another colour or finish?
Yes. Powder-coated versions are offered in RAL 1023 traffic yellow or another RAL colour. Hot-dip galvanized and galvanized plus powder-coated finishes are also available. A 304L stainless steel version can be requested. The viewer colours are screen approximations.
Which DOCK ANGEL versions are covered by TÜV certification?
We, Euro Industry, are the manufacturer of DOCK ANGEL. The current TÜV certificate does not presently cover DAS-2000, DAM models with an overall width of 3,400 mm and above, or any DAL models. An extension of the TÜV certification to cover these versions is currently in progress. Contact us for the certificate and documentation applicable to your version.
Does the 3D experience work on my phone?
You can rotate and zoom the model in modern browsers. Camera-based AR uses WebXR or Android Scene Viewer on compatible Android devices and Quick Look on supported iPhones. Camera access is requested only when AR is launched. Device support varies; use the 3D viewer when AR is unavailable.
Your next step
Select and order
your DOCK ANGEL.
Choose the model, surface finish, opening direction and optional warning light in the Euro Industry shop. Contact Euro Industry for other RAL colours, stainless steel versions or installation questions.
Buy it here ↗+49 (0) 711 460 59 21 40 ↗Contact Euro Industry ↗
